1SS355

  • Mfr Part #1SS355
  • ManufacturerHottech
  • HQ Part #DS0140094
  • PackageSOD323
  • Lead Time Ship immediately
  • DescriptionDiode configuration: Independent DC reverse voltage withstand (Vr) : 80V Average rectifier current (Io) : 100mA forward voltage drop (Vf) : 1.2V@100mA Reverse current (Ir) : 100nA@80V Reverse recovery time (trr) : 4ns

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Maximum Dissipated Power200mW
Reverse Peak Voltage (Maximum)80V
Diode ConfigurationSingle
Operating Temperature-55℃~150℃
Reverse Withstand Voltage Vr80V
Average Rectified Current100mA
Forward Voltage Drop Vf1.2V
Reverse Recovery Time (trr)4ns
Reverse Leakage Current Ir100nA
Package / CaseSOD323
Installation TypeSMT
Forward Voltage VF Max1.2V
Vf(Max Instantaneous Forward Voltage)1.2V
Ifsm - Peak Forward Surge Current2A
Partlife CycleActive
Storage Temperature-55~+150℃
Lead Quantity2pin
Height1.00mm
L x W/Size1.70 x 1.30mm
Country of OriginChina
Original ManufacturerGuangdong Hottech Co. Ltd.
BrandHottech
Application-
Forward Current225mA
Total Capacitance C3pF
Series-
Part StatusActive
