UM4684H

  • Mfr Part #UM4684H
  • ManufacturerUnion
  • HQ Part #IC0473496
  • PackageCSP10_2.1X1.6MM
  • Lead Time Ship immediately
  • DescriptionCSP-10(2.0x1.5) Analog Switches / Multiplexers ROHS

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Number Of Circuits2
Multiplexer/Demultiplexer Circuit2:1
Supply Voltage, Single (V+)1.8V~5.5V
Supply Voltage, Dual (V ±)1.8~5.5V
-3db Bandwidth20MHz
Package / Case-
On Resistance-
On Resistance-
Leakage Current2nA
Lead Quantity10Pins
Height-
L x W/Size2.10 x 1.60mm
Partlife CycleActive
Mounting TypeSMT
Country of OriginChina
Original ManufacturerUnion Semiconductor Limited.
Crosstalk -69dB@100kHz
Channel Capacitance (Cs (Off), Cd (Off))10pF
Part StatusActive
Switch CircuitSPDT
Number Of Channels2
Operating Temperature-40°C~85°C(TA)
