Images are for reference only

Zener / Zener Diodes ST MM1Z5V1

  • Mfr Part #MM1Z5V1
  • ManufacturerST
  • HQ Part #DS0137346
  • PackageSOD123
  • Lead Time Ship immediately
  • DescriptionVz=5.1V ±5% 5mA 0.5W

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Reverse Current Izt-
Voltage Stabilizing Value Vz5.1V
Dynamic Resistance (Maximum)130 Ohms
Maximum Dissipated Power500mW
Operating Temperature-50~+150℃
Moisture Sensitivity Level (Msl)-
Forward Voltage Drop Vf900mV
Reverse Leakage Current Ir2µA
Package / CaseSOD123
Installation TypeSMT
Forward Voltage VF Max900mV
