Schottky Diode DIODES BAT54SW-7-F

  • Mfr Part #BAT54SW-7-F
  • ManufacturerDIODES
  • HQ Part #DS0028123
  • PackageSOT323
  • Lead Time Ship immediately
  • Description30V 1V@100mA 200mA SOT-323-3 Schottky Barrier Diodes (SBD) ROHS

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Maximum Dissipated Power200mW
Reverse Peak Voltage (Maximum)30V
Current Average Rectification (Io) (Per Diode)200mA(DC)
Diode Configuration-
Operating Temperature Junction-65°C~125°C
Operating Temperature-65~+125℃
Moisture Sensitivity Level (Msl)-
Diode Type-
Reverse Withstand Voltage Vr30V
Average Rectification Current If200mA
Forward Voltage Drop Vf1V
Reverse Recovery Time (trr)5ns
Reverse Leakage Current Ir2µA
Supplier Device PackagingSOT-323
Package / CaseSOT323
Installation TypeSMT
Forward Continuous Current200mA
Forward Voltage VF Max1V
DC Reverse Current If Max2μA
Ifsm - Peak Forward Surge Current600mA
Breakdown Voltage30V
Storage Temperature-65~+125℃
Lead Quantity2pin
L x W/Size2.15 x 1.30mm
Country of OriginAmerica
Original ManufacturerDiodes Incorporated
Total Capacitance C10pF
Part StatusActive
Lead Free Or NotNo
