Schottky Diode DIODES B0520WS-7-F

  • Mfr Part #B0520WS-7-F
  • ManufacturerDIODES
  • HQ Part #DS0002762
  • PackageSOD323
  • Lead Time Ship immediately
  • Description20V 430mV@500mA 500mA SOD-323 Schottky Barrier Diodes (SBD) ROHS

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Maximum Dissipated Power235mW
Reverse Peak Voltage (Maximum)20V
Operating Temperature Junction-55°C~125°C
Moisture Sensitivity Level (Msl)-
Diode Type-
Reverse Withstand Voltage Vr20V
Average Rectification Current If500mA
Forward Voltage Drop Vf430mV
Reverse Recovery Time (trr)-
Reverse Leakage Current Ir250µA
Supplier Device PackagingSOD-323
Package / CaseSOD323
Installation TypeSMT
Forward Voltage VF Max430mV
Ifsm - Peak Forward Surge Current2A
Breakdown Voltage20V
Partlife CycleActive
Storage Temperature-55~+125℃
Lead Quantity2pin
L x W/Size1.80 x 1.40mm
Country of OriginAmerica
Original ManufacturerDiodes Incorporated
Total Capacitance C58pF
Part StatusActive
Lead Free Or NotYes
