ESD Suppressor / TVS Diodes ON NUP2105LT1G

  • Mfr Part #NUP2105LT1G
  • ManufacturerON
  • HQ Part #CP0103362
  • PackageSOT23
  • Lead Time Ship immediately
  • DescriptionESD VRWM=24V VBR(Min)=26.2V VC=44V IPP=8A Ppp=350W SOT23

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Size3.04 x 1.40mm
Peak Pulse Current (Ipp)8A
Supplier Device PackagingSOT-23-3(TO-236)
Junction Capacitance Value30pF@1MHz
Installation TypeSMT
Operating Temperature-55~+150℃(TJ)
Clamp Voltage Vc44V
Peak Pulse Power350W
Breakdown Voltage V (Br) - Min26.2V
Polarity (Single And Two-Way)Bidirectional
Package / CaseSOT23
Lead Spacing1.9mm
Lead Quantity3Pin
Breakdown Voltage Min26.2V
Supply Voltage24V
Voltage - Off State24V
Part StatusActive
Number Of Channels2
Power Line Protection-
Moisture Sensitivity Level (Msl)-
ApplicationAutomobile grade
Lead Free Or NotYes
Power Peak Pulse350W
Manufacturer'S Standard Lead Time-
