Darlington Triodes TI ULN2803ADWR

  • Mfr Part #ULN2803ADWR
  • ManufacturerTI
  • HQ Part #DS0126283
  • PackageSOIC18_300MIL
  • Lead Time Ship immediately
  • DescriptionDarlington Triodes SOIC18_300MIL IC=500mA VCC=50V VF=2V

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Forward Voltage (Vf) (Typical Value)1.7V
Operating Temperature-65~150℃
Installation Type-
Collecting Emitter Breakdown Voltage Vce (Max)50V
Transistor TypeNPN
DC Current Gain (hFE) (Min&Range)-
Transition Frequency-
Collector Current Ic (Max)500mA
Package / CaseSOIC18_300MIL
Current Magnification Hfe (Minimum)-
Vce Saturation Value (Maximum)1.6V@500µA,350mA
Collector Current Ic (Maximum)500mA
Transistor Type-
Supplier Device Packaging18-SOIC
Package / CaseSOIC-18 (0.295", 7.50mm Width)
Installation Type-
Operating Temperature-65°C~150°C(TJ)
Lead Spacing1.27mm
Collector Current Ic500mA
Power Dissipation-
Collector- Emitter Voltage VCEO50V
Partlife CycleActive
Storage Temperature-65~+150℃
L x W/Size11.55 x 7.50mm
Country of OriginAmerica
Original ManufacturerTexas Instruments Incorporated
Lead Free Or NotYes
Part StatusActive
Lead Free Or Not-
Voltage - Collector And Emitter Breakdown (Maximum)50V
Manufacturer'S Standard Lead Time-
Moisture Sensitivity Level (Msl)-
