BAV70

  • Mfr Part #BAV70
  • ManufacturerHottech
  • HQ Part #DS0140099
  • PackageSOT-23
  • Lead Time Ship immediately
  • Description70V +150℃@(Tj) 225mW Dual Common Cathode 1.25V@150mA 6ns 2.5uA@70V 200mA SOT-23 Switching Diode ROHS

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Maximum Dissipated Power225mW
Reverse Peak Voltage (Maximum)70V
Operating Temperature+150℃(TJ)
Reverse Withstand Voltage Vr70V
Average Rectified Current200mA
Reverse Recovery Time (trr)6ns
Reverse Leakage Current Ir2.5µA
Package / CaseSOT23
Installation TypeSMT
Forward Voltage VF Max1.25V
Forward Voltage VF Min715mV
Ifsm - Peak Forward Surge Current2A
Breakdown Voltage70V
Storage Temperature-55~+150℃
Lead Quantity3Pin
Height1.05mm
L x W/Size3.00 x 1.40mm
Country of OriginChina
Original ManufacturerGuangdong Hottech Co. Ltd.
BrandHottech
Application-
Forward Current200mA
Total Capacitance C1.5pF
SeriesBAW56/BAV70/BAV99
Part StatusActive
