Images are for reference only

3296X-1-103

  • Mfr Part #3296X-1-103
  • ManufacturerBOCHEN
  • HQ Part #AR0019209
  • PackagePOTENTIONMETER_9.5X4.85MM_TM
  • Lead Time Ship immediately
  • DescriptionPrecision Potentiometers POTENTIONMETER_9.5X4.85MM_TM 10KΩ ±10% 1/2W ±250ppm/℃

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Adjustment TypeSide adjustment
Number Of Turns25
Package / CasePOTENTIONMETER_9.5X4.85MM_TM
Size9.50 x 4.85mm
Installation TypeDIP
Operating Temperature-55℃~125℃
Temperature Coefficient±250ppm/℃
Power1/2W
Accuracy±10%
Technology/Process-
Rated Voltage640V
Height10.00mm
Partlife CycleActive
Storage Temperature-55~+125℃
CertificationRoHS
Country of OriginChina
Original ManufacturerChengdu Guosheng Technology Co.,Ltd.
BrandBOCHEN
GradeCommercial
Resistance Material-
Series3296X
Lead Free Or NotYes
Number Of Pins3Pins
ApplicationConsumer
Resistance10KΩ
