2N7002_R1_00001

  • Mfr Part #2N7002_R1_00001
  • ManufacturerPANJIT
  • HQ Part #DS0143092
  • PackageSOT-23
  • Lead Time Ship immediately
  • Description60V 250mA 5Ω@10V,500mA 350mW 2.5V@250uA N Channel SOT-23 MOSFETs ROHS

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
To ConfigureSingle
Continuous Drain Current250mA
Threshold Voltage2.5V
Drain Source Voltage (Vdss)60V
Operating Temperature-55~+150℃
Installation Type-
Transistor Type-
Power Dissipation350mW
Power (Watts)350mW
Total Gate Charge0.7nC
Breakdown voltage of grid and source±20V
PolarizationN-Channel
Partlife CycleActive
Storage Temperature-55~+150℃
Lead Quantity3Pin
Height1.10mm
L x W/Size3.04 x 1.40mm
Country of OriginChina Taiwan
Original ManufacturerPANJIT International Inc.
BrandPANJIT
Rdson (Maximum) For Different Ids And Vgs7.5Ω
Lead Free Or NotNo
Part StatusActive
