DMG1013UW-7
- Mfr Part #DMG1013UW-7
- ManufacturerDIODES
- HQ Part #DS0075202
- PackageSOD323
- Lead Time Ship immediately
Description20V 820mA 310mW 750mΩ@4.5V,430mA 1V@250uA P Channel SOT-323 MOSFETs ROHS
- Customer #
- Datasheet Datasheet
Product Attributes View Similar
| Type | Description | Select |
|---|---|---|
| Product Type | ||
| Continuous Drain Current | 820mA | |
| Grid Charge (Qg) | 0.622nC | |
| Threshold Voltage | 1V | |
| Vgs(Max) | ±6V | |
| Drain Current | 820mA | |
| Drain Source Voltage (Vdss) | 20V | |
| Operating Temperature | -55℃~+150℃(TJ) | |
| Installation Type | SMT | |
| Transistor Type | P-Channel | |
| Package / Case | SOD323 | |
| Conduction Resistance (RDS (on) @ Vgs, Id) | 750mΩ@4.5V,430mA | |
| Power Dissipation | 310mW | |
| Power (Watts) | 310mW | |
| Total Gate Charge | 0.622nC | |
| Reverse Transfer Capacitance | 6.36pF | |
| Breakdown voltage of grid and source | ±6V | |
| Breakdown Voltage | 20V | |
| Halide Free | Yes | |
| Polarization | P-Channel | |
| Partlife Cycle | Active | |
| Storage Temperature | -55℃~+150℃ | |
| Lead Quantity | 3Pin | |
| Height | 0.95mm | |
| L x W/Size | 2.15 x 1.30mm | |
| Certification | RoHS,HF(halogen free) | |
| Country of Origin | America | |
| Original Manufacturer | Diodes Incorporated | |
| Type | 1 P channel | |
| Input Capacitance Ciss | 59.76pF | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Lead Free Or Not | Yes | |
| Series | - | |
| Part Status | Active |
