NCP1117ST33T3G

  • Mfr Part #NCP1117ST33T3G
  • ManufacturerON
  • HQ Part #IC0233286
  • PackageSOT-223-3
  • Lead Time Ship immediately
  • DescriptionOutput type: Fixed Output polarity: positive Maximum input voltage: 20V Output voltage: 3.3V Output current: 1A

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Lead Quantity4Pin
Output Voltage Accuracy±1%
Quiescent Current10mA
Output Current1A
Type Of OutputFixed
Output ConfigurationPositive
Output Voltage 3.3V
Topological Structure Step-Down (Buck)
Package / CaseSOT-223-3
Installation TypeSMT
Number of Output Channels1
Number of Regulators1
Input Voltage Range20V
Forward Voltage VF Max1.2V
PolarizationPositive electrode
Power Supply Rejection Ratio(PSRR)64dB
Partlife CycleActive
Storage Temperature-65℃~+150℃
Country of OriginAmerica
Original ManufacturerON Semiconductor Inc.
Height1.80mm
Size6.50 x 3.50mm
CharacteristicOver Current, Over Temperature
Operating Temperature0℃~+125℃(TJ)
Series-
Lead Free Or NotYes
