2SA2198
- Mfr Part #2SA2198
- ManufacturerSPTECH
- HQ Part #DS0141847
- PackageTO3PML
- Lead Time Ship immediately
Description10uA 50V 60W 50@5A,1V 12A 25MHz 500mV@5A,80mA PNP +150℃@(Tj) TO-3PN Bipolar Transistors - BJT ROHS
- Customer #
- Datasheet Datasheet
Product Attributes View Similar
| Type | Description | Select |
|---|---|---|
| Product Type | ||
| To Configure | Single | |
| Vce Saturation Pressure Drop | 500mV | |
| Operating Temperature | +150℃ | |
| Installation Type | DIP | |
| Collecting Emitter Breakdown Voltage Vce (Max) | 50V | |
| Transistor Type | PNP | |
| DC Current Gain (hFE) (Min&Range) | 50 | |
| Transition Frequency | 25MHz | |
| Package / Case | TO3PML | |
| Collector Current Ic | 12A | |
| Power Dissipation | 60W | |
| Collector- Emitter Voltage VCEO | 0.5V | |
| Base-Emitter On Voltage VBE(on) | 1.2V | |
| Emitter-Base Voltage VEBO | 6V | |
| Collector Base Voltage (VCBO) | 70V | |
| Polarization | PNP | |
| Packaging Technology | DIP | |
| Storage Temperature | -55~+150℃ | |
| Lead Quantity | 3Pin | |
| Height | 26.00mm | |
| L x W/Size | 20.00 x 5.60mm | |
| Country of Origin | China | |
| Original Manufacturer | SPTECH Electronics Co. Ltd | |
| Brand | SPTECH |
