Images are for reference only

ESD Suppressor / TVS Diodes SOCAY SE03D3D01GE

  • Mfr Part #SE03D3D01GE
  • ManufacturerSOCAY
  • HQ Part #DS0139652
  • PackageSOD323
  • Lead Time Ship immediately
  • DescriptionESD suppressor /TVS diode VRWM=3.3V VBR(Min)=4V VC=16V IPP=18A SOD323

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Size1.80 x 1.40mm
Height1.00mm
Peak Pulse Current (Ipp)18A
Installation TypeSMT
Operating Temperature-40~+120℃
Breakdown Voltage V (Br) - Min4V
PolarityBidirectional
Package / CaseSOD-323
Lead Quantity2Pin
Breakdown Voltage Max6V
Partlife CycleActive
Country of OriginChina
Original ManufacturerShenZhen Socay Electronics Co., Ltd.
BrandSOCAY
Supply Voltage3.3V
Off State Voltage3.3V
Part StatusActive
Number Of Channels2
Lead Free Or NotYes
Power Peak Pulse-
