ADUM1201ARZ-RL7

  • Mfr Part #ADUM1201ARZ-RL7
  • ManufacturerADI
  • HQ Part #IS0012138
  • PackageSOIC8_150MIL
  • Lead Time Ship immediately
  • Description1 2.7V~5.5V -55℃~+100℃ Magnetic isolation Without voltage isolation 1 2 1Mbps General-purpose SOIC-8 Digital Isolators ROHS

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Transmission Speed 1Mb/s
Number Of Circuit Groups (Number Of Channels)2Channel
Rise/Fall Time (Typical Value)10ns
Installation TypeSMT
Package / CaseSOIC8_150MIL
Working Voltage 2.7V~5.5V
Lead Quantity8Pins
CertificationRoHS
Partlife CycleActive
Height1.55mm
L x W/Size4.90 x 3.90mm
Country of OriginAmerica
Original ManufacturerAnalog Devices, Inc.
BrandADI
Isolation Voltage2.5KV
Propagation Delay Tplh/Tphl (Maximum)150ns,150ns
Moisture Sensitivity Level (MSL)-
Series-
Part StatusActive
Operating Temperature-40°C~105°C
