Passive Crystal Oscillators TKD 49S-12-20-20

  • Mfr Part #49S-12-20-20
  • ManufacturerTKD
  • HQ Part #CR0250156
  • PackageHC49S
  • Lead Time Ship immediately
  • DescriptionPassive Crystal Oscillators 40Ω 12MHz 20pF ±20ppm HC49S -40℃~+85℃

  • Customer #
  • Datasheet Datasheet
Product Attributes View Similar
TypeDescription Select
Product Type
Annual Aging Rate±3ppm/year
Lead Quantity2Pin
Dominant Frequency12MHz
Installation TypeDIP
Frequency Error±20ppm
Size11.05 x 4.65mm
Package / CaseHC49S
Operating Temperature-40~+85℃
OvertoneFundamental
MaterialQuartz Crystal
Pb FreeYes
Product StateActive
Insulation Resistance500MΩ @ DC100V
Packaging TechnologyResistance weld
Drive Level10μW
Shunt Capacitance(C0)7pF
Cut TypeAT Cut
Partlife CycleActive
Output WaveSine Wave
Storage Temperature-40~+85℃
Country of OriginChina
Original ManufacturerTKD Science and Technology Co., Ltd.
Frequency Stability±30ppm
Series49S
Equivalent Series Resistance40Ω
Load Capacitance20pF
Height3.50mm
