STGWT80H65DFB
- Mfr Part #STGWT80H65DFB
- ManufacturerST
- HQ Part #DS0108147
- PackageTO-247-3
- Lead Time Ship immediately
DescriptionTO-3P-3 IGBTs ROHS
- Customer #
- Datasheet Datasheet
Product Attributes View Similar
| Type | Description | Select |
|---|---|---|
| Product Type | ||
| Forward Current | 120A | |
| Grid Charge (Qg) | 414nC | |
| Vce Saturation Pressure Drop | 1.6V | |
| Operating Temperature | -55℃~+175℃ | |
| Installation Type | DIP | |
| Collecting Emitter Breakdown Voltage Vce (Max) | 650V | |
| Transistor Type | - | |
| DC Current Gain (hFE) | - | |
| Transition Frequency | - | |
| Package / Case | TO-247-3 | |
| Collector Current Ic | 80A | |
| Power Dissipation | 470W | |
| Collector- Emitter Voltage(VCE(sat)) | 650V | |
| Turn-off Delay Time | 77ns | |
| Turn-on Delay Time | 328ns | |
| Reverse Recovery Charge | 4920nC | |
| Turn-off Energy | 4.4mJ | |
| Turn-on Energy | 2.1mJ | |
| Partlife Cycle | Active | |
| Storage Temperature | -55℃~+150℃ | |
| Lead Quantity | 3Pin | |
| Height | 20.15mm | |
| L x W/Size | 15.75 x 5.15mm | |
| Country of Origin | Switzerland | |
| Original Manufacturer | STMicroelectronics | |
| Reverse Recovery Time (trr) | 85ns | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Lead Free Or Not | Yes | |
| Series | - | |
| Part Status | Active |
